10.2″ (16:9) · 1024 × 600 · Cortex A8 600MHz
Samkoon SK-102HW is an industrial operator panel whose display, processing and communication details are organised below for practical machine integration.
Use the official drawing together with the nominal catalogue values when planning panel machining and terminal access.
All source-qualified values are visible by topic; no decision-critical data is hidden behind an expandable panel.
| Display size | 10.2″ (16:9) |
|---|---|
| Resolution | 1024 × 600 |
| Outer dimensions | 275 × 211 × 44 mm |
| Panel cut-out | 259 × 201 mm |
| Weight | 1050 g |
| Enclosure material | Engineering plastic ABS + PC |
| Touch panel | 4-wire high-precision touch panel |
| Colour depth | 16.7 million |
| Backlight | LED |
| Contrast ratio | 450:1 |
| Brightness | 500 cd/m² |
| Processor | Cortex A8 600MHz |
|---|---|
| Memory | 256MB FLASH + 128MB DDR3 |
| Protection rating | IP65 (front panel) |
| Dielectric withstand | 1000V AC, 1 minute |
| ESD resistance | Level 4, ±8kV |
| FCC | Class A |
| CE | EN55032 / EN55035 |
| Power supply | DC 12–24V ±15% |
|---|---|
| Power consumption | 7W |
| Serial ports | COM1 and COM2 (RS232 / RS422 / RS485) |
| Ethernet | Yes |
| USB download port | Yes |
| USB | Yes |
| CAN | Yes |
| Network connectivity | Wi-Fi: Yes; 3G: Yes; Ethernet: Yes; 4G: No |
| Operating temperature | -20°C to 55°C |
|---|---|
| Programming software | SKTOOL 6.0 / 6.2 / 7.0 |
| Operating humidity | 5% to 95% RH |
| Vibration resistance | 10–25Hz, XYZ direction, 2G / 30 minutes |
| SD card slot | No |
|---|
Compare published technical values and the complete model code before selection.
Cross-verified official record — The English catalogue record is also corroborated by another official Samkoon .cn catalogue or support source.
Official sources checked on 24 August 2026. Samkoon English product catalogue · Samkoon .cn catalogue/support record
