Display: 10.2 inch (16:9) · Resolution: 1024 × 600
Samkoon HMI
Samkoon SK-102QF
Display: 10.2 inch (16:9) · Resolution: 1024 × 600 · CPU: Cortex A7 1 GHz, dual-core
Samkoon SK-102QF is an industrial operator panel in the 3.5–15.6-inch HMI options differentiated by display, ports, Ethernet, Wi-Fi and enclosure range. Its display, processing, communications and mounting data are presented as one engineering selection flow.
Display size10.2 inch (16:9)
Resolution1024 × 600
ProcessorCortex A7 1 GHz, dual-core
EthernetNo
Serial portsCOM1: RS485
Protection ratingIP67 (entire unit)
Four points that define this configuration
Each point is tied to published model data or an explicit engineering verification step.
Processing platform
CPU: Cortex A7 1 GHz, dual-core · Memory: 128 MB DDR3 · Software: SKTOOL 7.1
Machine communications
Ethernet: No · Serial ports: COM1: RS485 · CAN: No
Panel integration
Outer dimensions: 276.5 × 193.5 × 37.7 mm · Panel cut-out: 263 × 180 mm · Protection: IP67 (entire unit)
System architecture
Build the HMI selection around three layers
Evaluate the operator experience, controller communications and physical panel integration as one system.
Operator layerDisplay: 10.2 inch (16:9) · Resolution: 1024 × 600
Communication layerEthernet: No · Serial: COM1: RS485 · CAN: No · Wireless: No
Panel layerDimensions: 276.5 × 193.5 × 37.7 mm · Cut-out: 263 × 180 mm · Protection: IP67 (entire unit) · Temperature: -20 °C – 55 °C (non-freezing)
Examine the product from every side
Review the front panel, rear I/O and connector layout before planning the enclosure.
Dimensions and panel cut-out
Use the official drawing together with the nominal catalogue values when planning panel machining and terminal access.
Specifications arranged for engineering review
All source-qualified values are visible by topic; no decision-critical data is hidden behind an expandable panel.
Display and mechanical
| Display size | 10.2 inch (16:9) |
|---|---|
| Resolution | 1024 × 600 |
| Outer dimensions | 276.5 × 193.5 × 37.7 mm |
| Panel cut-out | 263 × 180 mm |
| Contrast ratio | 400:1 |
| Brightness | 450 cd/m² |
| Weight | 980 g |
| Touch panel | 4-wire high-precision resistive panel |
| Colour depth | 16.77 million colours |
| Backlight | LED |
| Enclosure material | ABS+PC engineering plastic |
System and certification
| Processor | Cortex A7 1 GHz, dual-core |
|---|---|
| Memory | 128 MB DDR3 |
| Storage | 128 MB FLASH |
| ESD resistance | ±6 kV |
| FCC | FCC Class A compliant |
| CE | EN 55032 and EN 55035 compliant |
| Protection rating | IP67 (entire unit) |
| Dielectric withstand | 1000 V AC, 1 minute |
Communication and power
| Power supply | (DC 12–24 V) ±15% |
|---|---|
| Power consumption | 7 W |
| Serial ports | COM1: RS485 |
| Additional communication port | No |
| USB download port | Yes |
| USB host port | Yes |
| Wi-Fi | No |
| Ethernet | No |
| 4G | No |
| 3G | No |
| CAN | No |
Environment and software
| Operating temperature | -20 °C – 55 °C (non-freezing) |
|---|---|
| Configuration software | SKTOOL |
| Operating humidity | 5–95% RH (non-condensing) |
| Programming software | SKTOOL 7.1 |
| Vibration resistance | 10–25 Hz (XYZ direction, 2 G / 30 min) |
Other technical details
